Your Fitness Signature

Measuring Fitness

Each person possesses a unique level of fitness for a given physical activity. Different activities possess different measures of fitness. Fitness for weight-lifting, for example, is measured by the amount of weight one is able to lift. Alternatively, success in sports such running, swimming and cycling are primarily determined by how fast one can complete a given distance. In stark contrast, performance in other activities such as golf or alpine skiing, are highly dependent upon skill, rather than fitness per se,

fitness measurement is different from a performance measurement as there are often many factors that influence the final end-result, independent of fitness. The fitness measurement is specific to the athlete, whilst the performance measurement is the ultimate outcome – the time to complete a distance, the mean power output, or the finishing position, for example. Cycling is one activity where the measurement of both fitness and performance are possible, using power meter instrumentation. This equipment enables athletes to perform testing in semi-controlled environments, to determine their fitness, whereas previously a laboratory was required. Furthermore, it allows the analysis of actual training and race performance, and from that we can infer an athlete’s fitness.

Fitness measurement has four main applications:

  1. To establish protocols to determine an athlete’s strengths, weaknesses, limiters and areas of improvement.
  2. For the prescription of individualized training, set relative to the fitness level of the athlete.
  3. To determine the success/failure of training program, by monitoring the change in fitness
  4. To establish athlete performance targets to be used in racing that assist the athlete in optimizing the pacing or tactics for an event.

As of today, there are many measures, or correlates of fitness – maximal oxygen update, lactates threshold(s), exercise economy/efficiency etc are all well known from laboratory based research. Within the field utilizing power meter measurements, the main measure of fitness in endurance cycling is Threshold Power (TPSee Threshold Power....). Often referred to as functional threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is... (FTPAlso referred to as Functional Threshold Power, it is regarded by most athletes as the power that can be sustained...), and generally used synonymously with the terms critical power, anaerobic threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is..., lactate threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is... , and others. Threshold Power as the highest power that an athlete can sustain without accumulating short-term fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... is a marker of fitness. Simplistically, the higher the threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is..., the higher the intensity an athlete can sustain without accumulating immediate fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power....

Recently, other measures have started to enter into the mainstream for the assessment of fitness – terms such as anaerobic work capacity, W-prime (W’) and functional reserve capacity (FRC). These are terms used to describe the amount of High Intensity EnergyAlso used as the acronym HIE, this is the amount of energy or work capacity an athlete has above Threshold... (HIESee High Intensity Energy....) you have available, or the available capacity to perform work above the threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is....

Another measure of fitness, particularly for cyclists that compete in shorter events or in events that require a final sprint is Peak PowerAs one of the three parameters that define an athlete's Fitness Signature, this is an athlete's highest possible power.  Sometimes... (PP). Although not an often discussed measure of endurance fitness per se, peak powerAs one of the three parameters that define an athlete's Fitness Signature, this is an athlete's highest possible power.  Sometimes... establishes the highest power one can achieve and is measured when the cyclist is in a fresh state.

Together – threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is..., high intensity energey, and peak powerAs one of the three parameters that define an athlete's Fitness Signature, this is an athlete's highest possible power.  Sometimes...formThis is determined by the formula Training Load - Recovery Load.  It is colour-coded on the XPMC chart according to... the cyclist’s fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used.... The higher any of these measures are, the fitter the cyclist.

The Concept of Power-Duration

When we measure the length of time an athlete can sustain a given power output, and plot the power output vs. the time, we obtain a Power-time (P-t) curve, also known as a Power-Duration (PD) curve, or sometimes simply a power curveSynonymous with Power-Duration Chart and Power-Duration Curve, this describes the relationship between how long an athlete can sustain a given.... This is commonly known as the power-duration relationship, and is evident across many dynamic sports in humans, in health and disease, and indeed right across the animal kingdom. It is a fundamental cornerstone of exercise physiology, and also of endurance performance.

We can visualize the fitness of an athlete using their power-duration curve, plotted as power output (in watts) vs. time (in seconds) using a logarithmic scale for visual clarity:PD Curve with HIE







On the chart above, the top left represents the athlete’s peak powerAs one of the three parameters that define an athlete's Fitness Signature, this is an athlete's highest possible power.  Sometimes... (PP), the bottom right the threshold power (TPSee Threshold Power....) and the region in between is the capacity available above threshold, i.e. your high intensity energyAlso used as the acronym HIE, this is the amount of energy or work capacity an athlete has above Threshold... (HIESee High Intensity Energy....). Thus a power-duration curve is a visual representation of a fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used....

During a steady-state effort from fresh-to-failure, that is, the athlete starts from a rested state and maintains a given power intensity until they are unable to sustain that intensity, the end-point of the effort rests on the power duration curve:

Steady-State to Failure

The points on your power-duration curve can also be considered as points-of-failure for steady-state efforts from rested states.  In Xert, points-of-failure are synonymous with maximal efforts.  In our definition, a maximal effortSynonymous with point-of-failure, this refers to moments during an activity where an athlete attempts to produce as much power as... is any time an athlete attempts to generate as much power as they have available.  Maximal power availableAlso referred to as MPA™, Maximum Power Available or Max Power Available, it is a measure of the maximal power... (MPAMPA stands for Maximum Power Available. It is a measure of the maximum power an athlete can generate at a given moment... More) is the term used that defines the maximal amount of power an athlete has available at any given moment.  Maximal efforts are points during an activity where an effort to produce as much power as possible occurred, i.e. both power and MPAMPA stands for Maximum Power Available. It is a measure of the maximum power an athlete can generate at a given moment... More are equal.  Typical examples of maximal efforts in cycling are as follows:

  1. During an all-out sprint or attack
  2. Failing to bridge
  3. Getting dropped
  4. Failing to sustain a target power during an effort, such as in a time-trial or fitness test

In each of these situations, if more power was available, it would have been used.  It is at these exact moments that one’s fitness is expressed.  It is also at these moments which define the points of the power-duration relationship.

A Deeper Look

The power-duration relationship notably, is in a constant state of flux.  During an activity, power-duration is affected intermittently by various types of fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power....  Fast-recovery fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... can be recovered during the activity.  This type of fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... reduces one’s power-duration relationship and thus points-of-failure happen sooner:

Fast-Recovery Fatigue

For longer activities, some fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... is accumulated which cannot be recovered easily.  This type of fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... takes much longer for the athlete to recover from and, within an activity, no recovery from this type of fatigueFatigue represents a reduction in an athlete's ability to produce power.  It either manifests as a reduction in Maximal Power... is possible:

Slow-Recovery Fatigue

Fitness Breakthroughs

If an athlete had performed an activity that expressed a fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... and then, during a subsequent activity the athlete was able to surpass what would normally have been a point-of-failure, the athlete has demonstrated an improved fitness level.  They have achieved a fitness breakthroughA fitness breakthrough is achieved when your power reaches or surpasses MPA for longer than 5 seconds during an activity.... More. Identifying fitness breakthroughs are critical in the assessment of a given athlete in terms of their fitness but, more importantly, it provides feedback about the success of a given training program or methods.

Determining MPAMPA stands for Maximum Power Available. It is a measure of the maximum power an athlete can generate at a given moment... More during an activity or workout and comparing it to the power output is a very powerful way of assessing the athlete’s fitness and performance.  We’ll cover the concept of MPAMPA stands for Maximum Power Available. It is a measure of the maximum power an athlete can generate at a given moment... More and MPAMPA stands for Maximum Power Available. It is a measure of the maximum power an athlete can generate at a given moment... More analysis techniques in our next blog.

Fitness Measures

Although a fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... provides a convenient way to define a power duration relationship, often working with three simultaneous measurements can be cumbersome.  In fact, for most athletes, improving all three in equal amounts isn’t always the optimal approach for their training goals.  One parameter may have more relative importance than another.

To simplify the management and reporting of fitness, Xert enables the ability to select a fitness measure.  Your fitness measure is a combination of your fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... parameters, and may also include your body mass, that helps you assess whether your fitness for the type of athletic events you are targeting, is increasing or decreasing.

Fitness measures combine all three fitness parameters by evaluating fitness as the maximal steady-state power that could be performed for a given duration, optionally accounting for body mass.  For example, the fitness measure well-suited for road sprinting is a 1 minute maximal steady-state power divided by your body mass (60s W/kg). Successful road sprinters tend to possess higher 60s W/kg and tracking your 60s W/kg power as your fitness measure, would enable you to see how your fitness as a road sprinter is progressing.

A Fitness Signature Calculator

Xert Online provides a handy  fitness signature calculator which enables the determination of your fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... using tested best-efforts. The calculator requires just 3 pairs of values. Typically, the 3 pairs are entered in order of duration, with your highest, peak-power tested effort first and your lowest threshold tested effort last. One other datapoint along your curve is needed to determine your fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used....

For example, say you know the maximal power you’ve been able to produce, 1000W lasted 3 seconds, a 20 minute test you performed recently you did at 300W and you did rested, hard, all-out efforts at 500W where you were able to hold them for 100 seconds.

The calculator establishes your fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... based on these three points and determined that your peak powerAs one of the three parameters that define an athlete's Fitness Signature, this is an athlete's highest possible power.  Sometimes... is 1004W, your threshold powerAlso used as an acronym TP in Xert and sometimes described using the more colloquial term FTP, Threshold Power is... is 278W and your high intensity energy is 26.6 kJ. These three values represent your signature based on the 3 power-duration values you provided.

Note that the signature is only an estimate of your fitness based on the three data points provided. Often, the fitness you had during the three individual tests varied so the determination of your fitness signatureIt is represented by three values: Threshold Power (TP),  High Intensity Energy (HIE) and Peak Power (PP). The three fitness values are used... is subject to variation from different fitness levels and day-to-day changes as a result from training and recovery.

To obtain a signature that is a representation of your fitness for a given point in time, we’ll need to look deeper into the data itself. That will be the topic of our next blog where we will explore the concept of maximal power availableAlso referred to as MPA™, Maximum Power Available or Max Power Available, it is a measure of the maximal power... in more detail.
